Zebra Family ®

Cycle lane separator to segregate traffic flows.

Zebra Family®
Zebra Family®, Zebra® 5

Zebra® 5

Zebra Family®, Zebra® 9

Zebra® 9

Zebra Family®, Zebra® 13

Zebra® 13

Zebra Family®, Zebra® 40

Zebra® 40

PLACE AN ORDER

Why Zebra Family®?

The Zebra Family® products are designed to improve citizens’ safety on the streets, and especially the safety of bike lane users. They allow the rapid transformation of the street through the construction of cycle lanes, sidewalk widening, and road narrowing at intersections.

Zebra Family® Configurations

OBLIQUE CONFIGURATION.

The oblique configuration of the Zebra Family® cycle lane separator increases the distance between road traffic and the cycle lane user. It creates a higher barrier to motor vehicles.

Parallel configuration with the recycled ZICLA product Zebra® bike lane separator from Family Zebra®
Visualize the Zebra Family® separator in augmented reality and integrate it into your project.
View in AR
Oblique configuration with the recycled ZICLA product Zebra® Family Zebra® bike lane separator

PARALLEL CONFIGURATION.

The parallel configuration of the Zebra Family® cycle lane separator is the best choice when buffer space is limited.
Oblique configuration with the recycled ZICLA product Zebra® Family Zebra® bike lane separator
Visualize the Zebra Family® separator in augmented reality and integrate it into your project.
View in AR
Parallel configuration with the recycled ZICLA product Zebra® bike lane separator from Family Zebra®

PEDESTRIAN AREA.

Sometimes the cycle lane is in a pedestrian area, where it is essential to prioritize pedestrians. The Zebra Family® planter can be used to mark out the space for the flow of bicycles not to interfere with pedestrians. It is an optimal solution for separating cycle paths and pedestrian paths on the same street level.
Use of pedestrian area with the recycled ZICLA product Zebra® | Family Zebra® Bike Lane Divider Planter
Visualize the Zebra Family® separator in augmented reality and integrate it into your project.
View in AR
Use of pedestrian area with the recycled ZICLA product Zebra® | Family Zebra® Bike Lane Divider Planter

NARROWING THE ROADWAY.

Zebra Family® planters can be use to widen sidewalks at intersections and to build projections quickly and economically.
Street view of Zebra Family, configuration for lane narrowing – ZICLA | Products
Visualize the Zebra Family® planter in augmented reality and integrate it into your project.
View in AR
Top view of Zebra Family, configuration for roadway narrowing – ZICLA | Products

Download all the technical documents for your project.

TECHNICAL DETAILS
2D/3D MODELS
INSTALLATION MANUAL
AUGMENTED REALITY

The Zebra Family® in detail

Ellipsoid shape.

The Zebra Family® cycle lane separators are ellipsoid in shape and have no sharp edges.

Zebra in detail – ZICLA | Products

Non-slip texture.

The surface roughness of the Zebra Family® cycle lane separator makes it slip-resistant.

ZICLA Zabra Family Zebra Family 9

Visibility.

The Zebra Family® separators and planter are highly visible day and night thanks to the retro-reflective stripes.

Sizes.

The Zebra Family® cycle lane separator is available in different sizes. This offers greater adaptability to diverse road and traffic characteristics.

Zebra Family® in detail, dimensions
Zebra® 13
Zebra® 9
Zebra® 5

Impact resistance.

The structural design of the Zebra Family® cycle lane separator generates high impact resistance from any angle. The anchor housings are displaced from their longitudinal axis to provide the best possible attachment to the road surface.

Customising the Zebra Family®

The color of the Zebra Family® cycle lane separator and planter strips can be customized to meet each city’s requirements.

Personalization of the Zebra Family® with colors – ZICLA | Products

Low maintenance.

The Zebra® planter has a water reservoir that makes maintenance minimal.

ZICLA Zabra Family Zebra Family 11

Substratum:
30 liters.

Deposit:
7 liters of water.

Zebra Planter in detail – ZICLA | Products

1
Gravel
15/30mm

2
Geotextile

3
Fixing holes
The planter has four holes for fixing it to the ground

4
Overflow

Recycled and recyclable materials

The way we work is in line with the circular economy and we focus on the resource cycle following a model based on reusing, repairing, remanufacturing and recovering existing materials and products, as opposed to using virgin materials. We manufacture all our products from recycled and recyclable materials.

Zebra® | Blend.

Made from various mixtures of industrial and post-consumer plastic waste, mostly PVC from leftover banners, hoses, electrical cable sheathing, out-of-standard batches, etc.

100% Recycled material with classic crushed T
ZICLA Zabra Family Zebra Family 14

Zebra® 5

2 kg
4 lb 7 oz
3.22 kg of CO2 eq/unit
19 lb 13 oz of CO2 eq/unit
Click Here
ZICLA Zabra Family Zebra Family 16

Zebra® 9

4.5 kg
9 lb 15 oz
5.69 kg of CO2 eq/unit
12 lb 9 oz of CO2 eq/unit
Click Here
ZICLA Zabra Family Zebra Family 18

Zebra® 13

8.5 kg
18 lb 12 oz
8.98 kg of CO2 eq/unit
19 lb 13 oz of CO2 eq/unit
Click Here

Zebra® | Zero.

Made from a material developed entirely from post-consumer plastic waste of municipal origin. This waste comes from refuse from packaging sorting plants.
100% Recycled material with classic crushed T
ZICLA Zabra Family Zebra Family 16

Zebra® 9

3.4 kg
7 lb 8 oz
3.81 kg of CO2 eq/unit
8 lb 6 oz of CO2 eq/unit
Click Here
ZICLA Zabra Family Zebra Family 18

Zebra® 13

6.1 kg
13 lb 7 oz
5.27 kg of CO2 eq/unit
11 lb 10 oz of CO2 eq/unit
Click Here

Zebra® | Recovered.

Made from Linear medium-density polyethylene (LMDPE) waste from the manufacturing processes of various rotomolded products, mainly consisting of parts that do not pass quality control or are distorted or contaminated or not the correct weight or color, etc.
100% Recycled material with classic crushed T
ZICLA Zabra Family Zebra Family 24

Zebra® 40

8 kg
17 lb 10 oz
9.52 kg CO2 eq/u
20 lb 16 oz of CO2 equiv/unit
Click Here

Discover how the Zebra Family® improves safety for bike lane users.

Top Zebra® videos

→ Do you want to use the Zebra Family® cycle lane separator in your urban project?

ZICLA Zabra Family Zebra Family 32

How to order

To process your order please contact our delegations at the details below:
Send us an email to info@zicla.com or call us to +1 305 460 3512 (USA) or +34 93 334 27 31 (ES) to order now.

Or fill the form below:

Our proposed solutions, configurations, and customizations. help experts in the cities or organizations that purchase our products to make their decisions, but they are purely consultative. Under no circumstances can they be considered construction documents. The experts from these cities or companies are solely responsible for adopting the final solutions, configurations or customizations and ensuring that these comply with the town planning, traffic, safety, or any other applicable regulations in force at all times in each location.
